A .935" diameter 240 volts single zone
B .935" diameter 240 volts two or three zone
C .685" diameter 240 volts single zone
D .685" diameter 240 volts two or three zone
E .935" diameter 480 volts single zone
F .935" diameter 480 volts two or three zone
G .685" diameter 480 volts single zone
H .685" diameter 480 volts two or three zone
Consult CEM Electric for other diameter and voltage limitations
Transition Bending
Mounting brackets or stop washers in unheated area Consult CEM Electric.
Ordering Information:
Provide catalog number if available, or contact CEM Electric
with complete application and process information.
A specific X-ROD will be designed.
|
Transition Adaptors
X-ROD
Diameter |
Diameter |
B |
| .495" |
1-3/8" |
1-1/2" |
| .685" |
1-3/8" |
1-1/2" |
| .935" |
1-3/8" |
1-1/2" |
X-ROD
Diameter |
Diameter |
B |
| .495" |
1-1/4" |
1-1/4" |
| .685" |
1-1/4" |
1-1/4" |
| .935" |
1-5/8" |
1-5/8" |
Watt Density
To determine watt density, cold areas need be subtracted from the Sheath Length to determine the Effective Heated Length. A
1" cold area exists at the bottom end of the X-ROD, and a 1" cold area is necessary between zones. The cold
area required at the termination area depends upon the ambient temperature. The minimum cold area is generally 18% of the entire
heated length and is increased as the ambient temperature increases. Consult CEM Electric for design assistance based upon application requirements.
|
|
| Dia. |
Min. Heated
Length Per Zone |
Min. Heated
Length |
Max. Heated
Length |
| .495" |
* |
8" |
170" |
| .685" |
8" |
8" |
172" |
| .935" |
8" |
8" |
165" |
| * .495" diameter available in single zone only |
| |
Type 1 |
Type 2 |
Type 3 |
Type 4 |
| Minimum
cold section at terminal end |
|
|
|
|
| .495" |
2" |
6-1/2" |
7-1/2" |
11" |
| .685" |
2" |
6-1/2" |
8" |
13" |
| .935" |
2" |
8" |
10" |
17" |
| Minimum
bending radius |
|
|
|
|
| .495" |
-- |
-- |
1-1/8" |
1-1/8" |
| .685" |
-- |
-- |
1-1/2" |
1-1/2" |
| .935" |
-- |
-- |
2-1/2" |
2-1/2" |
| Minimum
straight length in cold section |
|
|
|
|
| .495" |
2" |
6-1/2" |
4" |
4"* |
| .685" |
2" |
6-1/2" |
4" |
4"* |
| .935" |
2" |
8" |
4" |
4"* |
| * 4" before termination - 1-1/2"
between radius of bends |
|
|
